Lubricant Oil Filling Technologies and Solutions
Maximum Precision and Speed with Midas Makina
Midas Makina offers solutions at the highest standards for filling products with different viscosities and chemical structures such as engine oil, lubricant oil, grease, transmission oil, and antifreeze. We use three main filling technologies in our lines custom designed according to your product type, packaging size, and target capacity: Loadcell Filling Machines (Weight Controlled), Flowmeter Filling Machines (Volumetric), and Servo Piston Filling Machines (Volumetric).
Loadcell Filling Machines (Weight Controlled)
When is it Used?
It is ideal for large packaging and products with high viscosity and foaming tendency.
Working Principle
The jerrycan, barrel, or IBC is placed on the weighing platform. Weight is continuously checked during filling, and filling ends at the targeted value.
Advantages
- High Precision: ±0.2 – 0.6 kg
- Product Independence: Unaffected by density, temperature, or foaming
Application Areas
- 20–30 kg jerrycan
- 200 L barrel
- 1000 L IBC filling
Typical Products
- High viscosity engine oils
- Greases
- Solvent-based chemicals
Flowmeter Filling Machines (Volumetric)
When is it Used?
It is the fastest solution in medium and low viscosity, fluid products, and high-capacity lines.
Working Principle
The product flow is measured with precise flowmeter sensors. Quick and repeatable filling is done thanks to volumetric adjustment.
Advantages
- High Speed: Excellent performance in small and medium packaging
- Flexibility: Coriolis (high precision) or magnetic flowmeter option
Application Areas
- 0.5 L, 1 L, 4 L, 5 L, and 20 L jerrycans
Typical Products
- Fluid engine oils
- Antifreeze
- Low-viscosity additive oils
Servo Piston Filling Machines (Volumetric)
When is it Used?
Superior accuracy in a wide viscosity range, especially for grease and semi-fluid products.
Working Principle
The servo motor-controlled piston transfers the product from the cylinder to the package in the set volume.
Advantages
- Wide Viscosity Range: From watery products to paste consistency
- Maximum Repeatability: High precision with servo control
Application Areas
- 0.25 L – 5 L small packages
Typical Products
- Grease
- Additive oils
- Industrial special liquids
Filling Line Complementary Units
- Capping: Servo torque-controlled Pick & Place or rotary capping systems
- Labeling: Double-sided or full wrap labeling, Herma brand solutions
- Safety: Closed cabin design, CE certified switches, optional ATEX compliance
Why Midas Makina for Lubricant Oil Filling?
- 25+ Years of Experience: Solutions suitable for the needs of the sector
- Triple Technology Expertise: Loadcell, Flowmeter, Servo Piston options
- Global Service Support: Max. 48-hour intervention domestically and internationally
- CE & ATEX Compliant Design: Safety for chemical and solvent-based products
